Switchcraft Controller

Switchcraft is the hydraulic control unit for a modernised lowrider setup. It replaces a bank of solenoids and relays with one controller: eight 15 A high-side outputs energise the dump valves that lower the car, and up to four EV motors driving hydraulic gear pumps raise it, each commanded over CAN through its own inverter.

Drive it from the built-in touchscreen, from the eight hard-wired switch inputs, or from a phone or computer over Bluetooth. The controller also serves its own web interface over WiFi, so any device with a browser can reach it without installing anything.

• 8 switch outputs, 15 A each, for dumps
• Up to 4 motors, commanded over CAN via Sevcon / Turntide Gen4 or generic CiA 402 inverters
• Capacitive touchscreen, 8 hard-wired inputs, Bluetooth apps, and an on-board web UI
• PyroFuse overcurrent protection with current sensing
• Field-updatable firmware
